Physical
- Unit dimensions, WxHxD: 6.1" x 1.6" x 5.0" (15.49 x 4.06 x 12.7 cm)
- Weight: 0.83 lbs (0.38 kg)
Performance
- Operating temperature: -20°C to +60°C (-4°F to 140°F)
- Operating altitude: To 55,000 ft
- Nominal operating velocity range: 0 – 800 kts (411 m/s)
- Power input: 10 to 32 VDC, 3.5 W max.
Connections
- 15-pin standard D-sub power and data connector
- ADS-B BNC antenna port
- SiriusXM® TNC antenna port
- GPS BNC antenna port
- Wireless Connext™ (Bluetooth®)
