Custom-fit car speaker systems are engineered to deliver incredible audio output with easy installation for most popular vehicles, including RAM, Toyota, & GMC.
General
|
| Warranty |
1 year |
| Sizes |
6 x 9″ |
| Continuous power handling (RMS) |
150 W |
| Sensitivity (SPL @ 1 W/1 m) |
86 dB |
| Frequency response (+/- 3 dB) |
36 Hz-19 kHz |
| Nominal impedance |
4 Ω |
| Recommended amplifier power (RMS) |
50-150 W/Channel |
| Cone material |
Mineral-filled polypropylene |
| Grille(s) included |
2.75″: yes |
Networking & Connections
|
| Speaker connections |
Spade connectors |
Mounting Dimensions
|
| Frame outer diameter |
2.75″: 2.85″ (72 mm)
6 x 9″: 6.38 x 9.13″ (162 x 232 mm) |
| Mounting depth clearance |
2.75″: 1.45″ (37 mm)
6 x 9″: 2.85″ (72 mm) |
| Frontal grille protrusion |
2.75″: 0.28″ (7 mm) |
| Motor outer diameter |
6 x 9″: 4.72″ (120 mm) |
Crossover Specifications
|
| Width |
2.53″ (64 mm) |
| Height |
1.93″ (49 mm) |
| Depth |
1.09″ (28 mm) |
