General |
|
| Warranty | 3 years |
|---|---|
| Physical dimensions (Height) | 3.74″ (95 mm) |
| Physical dimensions (Width) | 4.65″ (118 mm) |
| Physical dimensions (Depth) | 3.67″ (93 mm) |
| Control Surface Dust/Water Rating (when properly installed) | IP66 |
| Operating temperature range | -4° F to +158° F (-20° C to +70° C) |
| Multi-language interface |
English |
Stereo Features |
|
| Display size | 2.8″ (71 mm) |
|---|---|
| Display type | color TFT LCD, backlit |
| Display resolution | 320 x 240 |
| Software updates | USB |
Sources |
|
| Supported sources |
Derived from host source unit |
|---|---|
| Supported audio formats (USB) | Derived from host source unit |
Networking & Connections |
|
| NMEA 2000® ports | 1 (micro-C connector) |
|---|---|
| NMEA 2000® LEN | 4 (200 mA) |
| USB 2.0 ports | 1 (software update only) |
